Запчасти Komatsu PC210LC-7-DG ОХЛАЖД-Е (РАДИАТОР) (С КОНДИЦИОНЕРОМ)(№-) СИСТЕМА ОХЛАЖДЕНИЯ

1

20Y-03-31111

RADIATOR CORE ASS'Y

2

20Y-03-22110

CAP

3

20Y-03-21981

PLUG

4

07000-11007

O-RING

5

203-03-41410

HOSE

6

20Y-03-11330

CLIP

7

01435-20816

BOLT

8

20Y-03-31241

SEAL

9

20Y-03-31251

SEAL

10

20Y-03-31260

SEAL

11

20Y-03-31270

SEAL

12

20Y-03-31151

FRAME

13

20Y-03-31161

FRAME

14

20Y-03-31170

FRAME

15

01010-81025

BOLT

16

01643-31032

WASHER

17

22U-03-21191

NET

18

01434-10616

BOLT¤ WING

19

01643-30623

WASHER

20

20Y-03-31181

PLATE

21

01010-81025

BOLT

22

01643-31032

WASHER

23

20Y-03-31420

NET

24

01434-10616

BOLT¤ WING

25

01643-30623

WASHER

26

20Y-03-31121

OIL COOLER ASS'Y

27

01010-81030

BOLT

28

01643-31032

WASHER

29

20Y-03-31480

VALVE ASS'Y

30

07000-12020

O-RING

31

07002-13034

O-RING

32

07040-11812

PLUG

33

07002-11823

O-RING

34

22U-03-21740

SHEET

35

20Y-03-31290

SEAL

36

22U-03-21760

SHEET

37

07040-11409

PLUG

38

07002-11423

O-RING
