Запчасти Komatsu PC210LC-6LE FIG NO. H-A ГИДР. БАК. (С ДАТЧИКОМ) ГИДРАВЛИКА

1

20Y-60-22612

TANK, HYDRAULIC

2

208-04-19130

ELBOW

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-02434

O-RING

6

209-62-57430

TEE

7

07002-02434

O-RING

8

07236-10522

ELBOW

9

07002-02434

O-RING

10

07235-10315

ELBOW

11

07002-02034

O-RING

12

07236-10315

ELBOW

13

07002-02034

O-RING

14

07236-10210

ELBOW

15

07002-01423

O-RING

16

20Y-60-21510

ELEMENT, HYDRAULIC TANK

17

206-60-41221

STRAINER, HYDRAULIC TANK

18

12R-60-11300

VALVE ASSEMBLY

19

20Y-60-21240

SPRING

20

20Y-60-22530

COVER

21

07000-05180

O-RING

22

01010-51230

BOLT

23

01643-31232

WASHER

24

7861-92-4210

SENSOR

25

01252-40612

BOLT

26

01641-20608

WASHER

|$26

20Y-60-22550

STRAINER ASSEMBLY

27

207-60-61150

ROD ASSEMBLY

28

20Y-60-21320

HOLDER

29

12R-60-11230

SPRING

30

20Y-60-21311

STRAINER, HYDRAULIC TANK

31

NSS

COVER

32

07000-05180

O-RING

33

01010-51225

BOLT

34

01643-31232

WASHER

35

20Y-60-21440

CAP

36

20Y-60-21460

NECK

37

205-60-66211

GASKET

38

01220-40516

SCREW

39

01601-20513

WASHER

40

07285-00155

CLIP

41

07270-61512

TUBE

42

01010-81635

BOLT

43

01643-31645

WASHER

44

20Y-60-22561

COVER

45

01220-40412

SCREW

46

20Y-60-22540

PLATE
