Запчасти Komatsu PC210LC-6LE FIG NO. T- ЦИЛИНДР КОВША ДЛЯ .9M РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

205-63-03131

CYLINDER ASSEMBLY, BUCKET

1

205-63-71141

CYLINDER

2

707-76-70110

BUSHING

3

07145-00070

SEAL, DUST

4

205-63-71121

ROD, PISTON

5

707-76-70120

BUSHING

6

21K-70-12180

SEAL, DUST

7

707-27-11981

HEAD, CYLINDER

8

07179-13094

RING, SNAP

9

195-63-92190

SEAL

10

707-52-90560

BUSHING

11

707-51-80030

PACKING, ROD

12

07000-15105

O-RING

13

707-35-91150

RING, BACK-UP

14

707-51-80630

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-11661

PISTON

18

707-44-11280

RING, PISTON

19

707-39-11510

RING, WEAR

20

707-44-11920

RING

21

707-35-90360

RING, BACK-UP

22

07000-15070

O-RING

23

01310-01216

SCREW

24

07020-00000

FITTING, GREASE

25

07020-00900

FITTING, GREASE

26

205-63-71171

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING

30

707-88-95370

BRACKET

31

707-88-95350

BAND

32

01010-81035

BOLT

33

01643-51032

WASHER

34

07282-02793

CLAMP

35

01010-81020

BOLT

36

01643-31032

WASHER

|$40

707-99-47670

SERVICE KIT, BUCKET CYLINDER

3

07145-00070

SEAL, DUST

6

21K-70-12180

SEAL, DUST

9

195-63-92190

SEAL, DUST

11

707-51-80030

PACKING, ROD

12

07000-15105

O-RING

13

707-35-91150

RING, BACK-UP

14

707-51-80630

RING, BUFFER

18

707-44-11280

RING, PISTON

19

707-39-11510

RING, WEAR

21

707-35-90360

RING, BACK-UP

22

07000-15070

O-RING

29

07000-13030

O-RING
