Запчасти Komatsu PC210LC-6LE FIG NO. T- ЦИЛИНДР СТРЕЛЫПРАВ. РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

206-63-03110

CYLINDER ASSEMBLY, R.H

1

206-63-54740

CYLINDER

2

206-70-55280

BUSHING

3

07145-00080

SEAL, DUST

4

206-63-54720

ROD, PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL, DUST

7

707-27-13921

HEAD, CYLINDER

8

07179-13104

RING, SNAP

9

195-63-94170

SEAL, DUST

10

707-52-90680

BUSHING

11

707-51-90030

PACKING, ROD

12

07000-15120

O-RING

13

707-35-91320

RING, BACK-UP

14

707-51-90630

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-13471

PISTON

18

707-44-13180

RING, PISTON

19

707-39-13110

RING, WEAR

20

707-44-13911

RING

21

707-71-60930

PLUNGER

22

07000-15080

O-RING

23

707-35-90940

RING, BACK-UP

24

01310-01216

SCREW

25

707-71-32680

COLLAR

26

707-35-91320

RING, BACK-UP

27

07000-15120

O-RING

28

206-63-54870

TUBE, R.H

29

206-62-64290

TUBE, R.H

30

01435-01055

BOLT

31

01435-01040

BOLT

32

07000-13030

O-RING

33

206-63-54292

BRACKET, R.H

34

707-88-95081

BAND

35

01010-81035

BOLT

36

01643-51032

WASHER

37

07283-22738

CLIP

38

01599-01011

NUT

39

01643-31032

WASHER
