Запчасти Komatsu PC210LC-6LE КОЛЕНВАЛ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC210LC-6LE - КОЛЕНВАЛ ДВИГАТЕЛЬ
5
8
3
2
6
7
1
6
4
4

Артикул

Название

Примечание

Количество

|$0

1240 355 H91

CRANKSHAFT ASSEMBLY

1

1294 364 H3

GEAR, CRANKSHAFT

2

NSS

CRANKSHAFT

3

6732-21-6150

PIN, DOWEL

|$4

1240 114 H91

SET, MAIN BEARING - STANDARD

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$8

1240 115 H91

SET, MAIN BEARING - 0.25MM OVER

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$12

1240 116 H91

SET, MAIN BEARING - 0.50MM OVER

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$16

1240 117 H91

SET, MAIN BEARING - 0.75MM OVER

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$20

1240 118 H91

SET, MAIN BEARING - 1.00MM OVER

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$24

6736-29-8700

SET, CRANKSHAFT THRUST BRG - 0.50MM OVER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$27

6736-28-8700

SET, CRANKSHAFT THRUST BRG - 1.00MM OVER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

7

1240 761 H1

KIT, FRONT CRANK SLEEVE

8

1305 044 H91

KIT, REAR CRANK SLEEVE (DRY FLYWHEEL)

|$32

1305 042 H1

SLEEVE, WEAR DRY

|$33

1305 045 H1

SEAL, OIL

|$34

1305 041 H91

KIT, REAR CRANK SLEEVE (WET FLYWHEEL)

|$35

1305 042 H1

SLEEVE, WEAR WET

|$36

1305 043 H1

SEAL, OIL

Выбрано товаров: 37
