Запчасти Komatsu PC210LC-6LC ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ - SD-

|$0

1295 324 H91

TURBOCHARGER

1

1240 503 H1

HOUSING, COMPRESSOR

2

1240 504 H1

DIFFUSER, TURBOCHARGER

3

1240 489 H1

SEAL, RECTANGULAR RING

|$4

1240 505 H91

ROTOR ASSEMBLY

4

1240 492 H1

NUT, LOCK

5

1240 493 H1

SLINGER, OIL

6

1240 494 H1

COLLAR, THRUST

7

1278 293 H1

SHAFT & WHEEL

8

NSS

IMPELLER, TUR COMPRESSOR

9

1246 480 H1

SEAL, SPLIT RING

10

1246 467 H1

BAFFLE, OIL

11

1246 465 H1

BOLT, FLAT HEAD CAP (M5x0.80x16)

12

1270 365 H1

BEARING, TUR THRUST

13

1240 510 H1

RING, RETAINING

14

1240 490 H1

BEARING, TURBOCHARGER

15

1246 481 H1

BOLT, HEXAGON HEAD SET (M8x1.25x12)

17

1240 487 H1

PLATE, CLAMPING

18

1278 296 H1

BOLT, HEXAGON HEAD SET

19

1240 498 H2

HOUSING, TUR BEARING

20

1240 496 H1

SHIELD, TURBOCHARGER HEAT

21

1246 479 H1

SEAL, SPLIT RING

22

1240 497 H1

HOUSING, TURBINE

23

1240 506 H1

O-RING

25

1246 472 H2

DATAPLATE

26

1246 471 H1

SCREW, DRIVE

27

1294 982 H91

CLAMP, V BAND

28

1241 715 H1

NUT, REGULAR HEXAGON

29

1240 576 H1

GASKET, TURBOCHARGER

30

1304 931 H1

GASKET, OIL DRAIN

N/I

1240 486 H1

LOCKPLATE

N/I

1246 470 H1

WASHER, LOCK
