Запчасти Komatsu PC210LC-6LC ТОПЛИВН. ВПРЫСК ДВИГАТЕЛЬ - SD-

Схема запчастей Komatsu PC210LC-6LC - ТОПЛИВН. ВПРЫСК ДВИГАТЕЛЬ - SD-
1
2
3
5
9
10
11
7
8
6
4

Артикул

Название

Примечание

Количество

1

6735-11-3120

KIT, FUEL INJECTOR

2

6732-11-3850

O-RING

3

6732-71-6230

WASHER, SEALING

4

6736-11-3430

SEAL, INJECTOR

5

NSS

INJECTOR, FUEL

6

1240 302 H1

RETAINER, INJECTION NOZZLE

7

1240 299 H1

SPRING, COMPRESSOR

8

1307 604 H1

SPINDLE

9

1307 605 H1

DISC, INTERMEDIATE

10

1240 617 H1

NOZZLE, INJECTOR

11

1240 303 H1

SHIM - 1.00MM

|$11

1240 304 H1

SHIM - 1.04MM

|$12

1240 305 H1

SHIM - 1.08MM

|$13

1240 306 H1

SHIM - 1.10MM

|$14

1240 307 H1

SHIM - 1.14MM

|$15

1240 308 H1

SHIM - 1.18MM

|$16

1240 309 H1

SHIM - 1.20MM

|$17

1240 310 H1

SHIM - 1.24MM

|$18

1240 311 H1

SHIM - 1.28MM

|$19

1240 312 H1

SHIM - 1.30MM

|$20

1240 313 H1

SHIM - 1.34MM

|$21

1240 314 H1

SHIM - 1.38MM

|$22

1240 315 H1

SHIM - 1.40MM

|$23

1240 316 H1

SHIM - 1.44MM

|$24

1240 317 H1

SHIM - 1.48MM

|$25

1240 318 H1

SHIM - 1.50MM

|$26

1240 319 H1

SHIM - 1.54MM

|$27

1240 320 H1

SHIM - 1.58MM

|$28

1240 321 H1

SHIM - 1.60MM

|$29

1240 322 H1

SHIM - 1.64MM

|$30

1240 323 H1

SHIM - 1.68MM

|$31

1240 324 H1

SHIM - 1.70MM

|$32

1240 325 H1

SHIM - 1.74MM

|$33

1240 326 H1

SHIM - 1.76MM

|$34

1240 327 H1

SHIM - 1.78MM

|$35

1240 328 H1

SHIM - 1.80MM

|$36

1240 329 H1

SHIM - 1.84MM

|$37

1240 330 H1

SHIM - 1.88MM

|$38

1240 331 H1

SHIM - 1.90MM

|$39

1240 332 H1

SHIM - 1.94MM

|$40

1240 333 H1

SHIM - 1.98MM

Выбрано товаров: 41
