Запчасти Komatsu PC210LC-6LC ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ - SD-

|$0

1296 013 H91

HEAD, CYLINDER

1

NSS

HEAD, CYLINDER

2

1295 538 H2

PLUG, EXPANSION

3

6732-11-1930

PLUG, PIPE - 1/8 NPT

4

6732-11-1910

PLUG, PIPE - 1/2 NPT

|$5

1240 104 H92

KIT, INTAKE VALVE

5

1240 127 H1

COLLET, VALVE

10

NSS

VALVE, INTAKE

|$8

1240 105 H92

KIT, EXHAUST VALVE

5

1240 127 H1

COLLET, VALVE

11

NSS

VALVE, EXHAUST

6

1304 604 H1

SPRING, VALVE

7

1240 132 H1

RETAINER, VALVE SPRING

8

1240 164 H1

SEAL, VALVE STEM

9

1304 603 H1

SEAL, VALVE STEM

12

6732-11-1920

PLUG, PIPE - 3/4 NPT

13

1294 507 H2

BOLT, HEX FLANGE HEAD CAP

14

1294 508 H2

BOLT, HEX FLANGE HEAD CAP

15

6735-11-1811

GASKET, CYLINDER HEAD - STD

|$19

1294 396 H2

GASKET, CYLINDER HEAD - .15MM OVERSIZE

|$20

1240 728 H3

GASKET, CYLINDER HEAD - .50MM OVERSIZE

16

1240 668 H1

INSERT, VALVE - EXHAUST

17

1240 779 H1

INSERT, VALVE - INTAKE

18

1240 677 H1

GUIDE, VALVE STEM - INTAKE (THICK WALL)

19

1240 678 H1

GUIDE, VALVE STEM - EXHAUST (THICK WALL)

20

1240 763 H1

GUIDE, VALVE STEM - INT/EXH (THIN WALL)
