Запчасти Komatsu PC210LC-6LC БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ - SD-

Схема запчастей Komatsu PC210LC-6LC - БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ - SD-
5
5
7
11
15
9
13
5
6
16
7
12
17
7
2
10
8
14
18
1
19
3
4

Артикул

Название

Примечание

Количество

|$0

6736-21-1100

BLOCK ASSY, CYLINDER

1

NSS

BLOCK, CYLINDER

2

6732-21-1410

BUSHING

3

6732-21-1610

BOLT (M14x2.00x119)

4

6732-21-1210

CAP, MAIN BEARING

5

6736-21-1810

PLUG, EXPANSION

6

6732-21-1820

PLUG, EXPANSION (1 INCH)

7

1240 152 H1

PLUG, EXPANSION (17.73 MM)

8

1240 121 H1

DOWEL, RING

|$9

6736-21-1090

KIT, BLOCK HARDWARE

9

6732-21-6140

DOWEL, RING (M16x10)

10

6732-21-1190

NOZZLE, PISTON

11

6732-21-6130

PLUG, WELCH

12

6732-21-6120

PIN DOWEL (M10x16)

13

6732-11-1910

PLUG, PIPE (1/2 NPT)

14

6732-11-1930

PLUG, PIPE (1/8 NPT)

N/I

6732-21-1930

O-RING

15

6735-21-5530

PLUG, EXPANSION (NOT USED ON TURBOCHARGED ENG)

16

6732-21-1810

DOWEL, RING (M18x10)

17

6732-21-5530

PLUG, EXPANSION

18

6732-21-6160

PLUG, EXPANSION

N/I

6732-21-1930

SEAL, O-RING

2

6736-29-1410

BUSHING, OS - NO. 1 BORE

2

6736-29-1420

BUSHING, OS - NO. 2-5 BORE

4

6732-21-1210

CAP, MAIN BEARING

19

6736-29-2110

SLEEVE, SALVAGE - STD BORE

Выбрано товаров: 26
