Запчасти Komatsu PC210LC-6L FIG NO. T- ЦИЛИНДР РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

205-63-02521

CYLINDER ASSEMBLY, ARM

1

205-63-63340

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL, DUST

4

205-63-63320

ROD, PISTON

5

707-27-13660

HEAD, CYLINDER

6

07179-13109

RING, SNAP

7

707-56-95510

SEAL, DUST

8

707-52-90710

BUSHING

9

707-51-95030

PACKING, ROD

10

07000-15130

O-RING

11

07001-05130

RING, BACK-UP

12

707-51-95630

RING, BUFFER

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-13500

PISTON

16

707-44-13280

RING, PISTON

17

707-39-13510

RING, WEAR

18

707-44-13920

RING

19

07165-16870

NUT

20

707-71-61001

PLUNGER

21

707-71-60230

PLUNGER

22

07020-00900

FITTING

23

707-71-32730

COLLAR

24

07001-05130

RING, BACK-UP

25

07000-15130

O-RING

26

04260-00635

BALL

27

707-71-91270

CAP

28

205-63-63370

TUBE

29

20D-62-17860

ELBOW

30

07372-21060

BOLT

31

07372-21045

BOLT

32

01643-51032

WASHER

33

07000-13030

O-RING

34

01010-51080

BOLT

35

01643-31032

WASHER

36

07000-13035

O-RING

37

707-88-95341

BRACKET

38

707-88-95320

BAND

39

01010-51035

BOLT

40

01643-51032

WASHER

41

707-88-11560

PLATE

42

07283-22738

CLIP

43

01599-01011

NUT

44

01643-31032

WASHER

|$48

707-99-57200

SERVICE KIT, ARM CYLINDER

3

07145-00080

SEAL, DUST

7

707-56-95510

SEAL, DUST

9

707-51-95030

PACKING, ROD

10

07000-15130

O-RING

11

07001-05130

RING, BACK-UP

12

707-51-95630

RING, BUFFER

16

707-44-13280

RING, PISTON

17

707-39-13510

RING, WEAR

33

07000-13030

O-RING

36

07000-13035

O-RING
