Запчасти Komatsu PC210LC-6L FIG NO. K7- КОНДИЦ. ВОЗДУХА (БЛОК) ДЛЯ MACHINES С SAE ЗАЩИТА ВЕНТИЛЯТОРА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-979-2112

UNIT ASSY, AIR CONDITIONER (WITH SAE FAN GUARD)

2

20Y-979-2930

MOTOR

3

20Y-979-2940

MOTOR

4

20Y-979-2950

MOTOR

5

20Y-979-2960

MOTOR

6

20Y-979-2970

VALVE

7

20Y-979-2980

RESISTOR

8

20Y-979-2990

SWITCH

9

20Y-979-2680

RELAY

10

14X-911-7741

FILTER

11

14X-911-7750

FILTER

12

20Y-979-2181

HOSE

13

01010-81030

BOLT

14

01643-31032

WASHER

15

07281-00419

CLAMP

16

203-979-6281

CONDENSOR ASSEMBLY

17

20Y-979-3120

RECEIVER

18

01010-81025

BOLT

19

01643-31032

WASHER

20

20Y-979-2851

BRACKET

21

01010-81025

BOLT

22

01643-31032

WASHER

23

07283-26155

CLIP

24

01599-01011

NUT

25

01643-31032

WASHER

27

20Y-03-21591

BRACKET

28

01010-51070

BOLT

29

01643-31032

WASHER

30

20Y-979-2453

BRACKET

31

01010-51030

BOLT

32

01643-31032

WASHER

33

01017-51400

BOLT

34

01580-11411

NUT

35

01010-50885

BOLT

36

01643-30823

WASHER

37

20Y-03-21551

COVER

38

01010-51025

BOLT

39

01643-31032

WASHER
