Запчасти Komatsu PC210LC-6L FIG NO. A-AD ПОРШЕНЬ & ШАТУН ДВИГАТЕЛЬ

1

6209-31-2180

PISTON, ENGINE - STD

|$1

6209-39-2180

PISTON, ENGINE - 0.25MM OVERSIZE

|$2

6209-38-2180

PISTON, ENGINE - 0.50MM OVERSIZE

2

6207-31-2420

PIN, PISTON

3

04065-03012

RING, SNAP

|$5

6209-31-2400

SET, PISTON RING - STD

4

NSS

RING, TOP

5

NSS

RING, SECOND

6

NSS

RING, OIL

|$9

6209-39-2400

SET, PISTON RING - 0.25MM OVERSIZE

4

NSS

RING, TOP

5

NSS

RING, SECOND

6

NSS

RING, OIL

|$13

6209-38-2400

SET, PISTON RING - 0.50MM OVERSIZE

4

NSS

RING, TOP

5

NSS

RING, SECOND

6

NSS

RING, OIL

|$17

6207-31-3500

CONNECTING ROD ASSEMBLY

7

6207-31-3510

ROD, ENGINE CONNECTING

8

6204-31-3121

CAP

9

6207-31-3530

BUSHING

10

6204-31-3310

BOLT

11

6207-31-3140

PIN

12

6207-31-3600

BEARING, CONN ROD - STD

|$24

6207-39-3600

BEARING, CONN ROD - 0.25MM UNDERSIZE

|$25

6207-38-3600

BEARING, CONN ROD - 0.50MM UNDERSIZE
