Запчасти Komatsu PC210LC-6L FIG NO. A-AB КОЛЕНВАЛ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC210LC-6L - FIG NO. A-AB КОЛЕНВАЛ ДВИГАТЕЛЬ
4
1
2
6
5
6
3
5

Артикул

Название

Примечание

Количество

|$0

6207-31-1100

CRANKSHAFT ASSEMBLY

1

NSS

CRANKSHAFT

2

6204-31-1220

GEAR, CRANKSHAFT

3

6206-31-1530

KEY

|$4

6204-21-8100

BEARING, MAIN - STD

4

NSS

BEARING, UPPER

5

NSS

METAL, LOWER

|$7

6204-29-8100

BEARING, MAIN - 0.25MM UNDERSIZE

4

NSS

BEARING, UPPER

5

NSS

BEARING, LOWER

|$10

6204-28-8100

BEARING, MAIN - 0.50MM UNDERSIZE

4

NSS

BEARING, UPPER

5

NSS

BEARING, LOWER

|$13

6204-27-8100

BEARING, MAIN - 0.75MM UNDERSIZE

4

NSS

BEARING, UPPER

5

NSS

BEARING, LOWER

|$16

6204-26-8100

BEARING, MAIN - 1.00MM UNDERSIZE

4

NSS

BEARING, UPPER

5

NSS

BEARING, LOWER

6

6204-21-8600

BEARING, THRUST - STD

|$20

6204-29-8600

BEARING, THRUST - 0.25MM OVERSIZE

|$21

6204-28-8600

BEARING, THRUST - 0.50MM OVERSIZE

|$22

6204-27-8600

BEARING, THRUST - 0.75MM OVERSIZE

|$23

6204-26-8600

BEARING, THRUST - 1.00MM OVERSIZE

Выбрано товаров: 24
