Запчасти Komatsu PC210LC-6K ГИДР. БАК. (С ДАТЧИКОМ)(№K-K) ГИДРАВЛИКА

|1

20Y-60-K1291

HYDRAULIC TANK ASS'Y

1

TANK

2

208-04-19130

ELBOW

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-12434

O-RING

6

07230-20628

UNION

7

07002-12434

O-RING

8

07236-10522

ELBOW

9

07002-12434

O-RING

10

07235-10315

ELBOW

11

07002-12034

O-RING

12

07236-10315

ELBOW

13

07002-12034

O-RING

14

07236-10210

ELBOW

15

07002-11423

O-RING

16

20Y-60-21510

ELEMENT

17

206-60-41221

STRAINER

18

12R-60-11300

VALVE ASS'Y

19

20Y-60-21240

SPRING

20

20Y-60-22530

COVER

21

07000-15180

O-RING

22

01010-81230

BOLT

23

01643-31232

WASHER

|24

20Y-60-K1280

STRAINER ASS'Y

24

203-60-56250

STRAINER

25

20Y-60-K1270

ROD

26

12R-60-11230

SPRING

27

20E-60-K1210

COVER

28

07000-15180

O-RING

29

01010-81225

BOLT

30

01643-31232

WASHER

31

17A-60-11310

CAP ASS'Y

32

20Y-60-21470

ELEMENT

33

20Y-60-21460

NECK

34

205-60-66211

GASKET

35

01023-10516

SCREW

36

01601-20513

WASHER,SPRING

37

07285-00155

CLIP

38

20Y-60-21190

TUBE

39

20Y-60-K1220

COVER

|39

20Y-60-22561

COVER

40

01023-10412

SCREW

|40

01220-40412

SCREW

41

20Y-60-22540

PLATE

42

01010-61635

BOLT

43

01643-31645

WASHER

44

195-03-11570

SHIM¤ 1.0MM

45

7861-92-4210

SENSOR

46

7861-92-4220

O-RING

47

01252-40612

BOLT

48

01641-20608

WASHER
