Запчасти Komatsu PC210LC-6K 1-Я СТРЕЛА ЦИЛИНДР (2-СЕКЦИОНН. СТРЕЛА) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

205-63-K1361

CYLINDER ASS'Y

|1

205-63-K1360

CYLINDER ASS'Y

1

205-63-K1380

CYLINDER

2

20Y-63-K1190

BUSHING

|2

707-76-70320

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

205-63-K1390

ROD,PISTON

5

707-76-80220

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12620

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90600

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15115

O-RING (KIT)

13

07001-05115

RING,BACK-UP (KIT)

14

707-51-85630

RING,BUFFER (KIT)

15

01010-61670

BOLT

16

01643-51645

WASHER

17

707-36-12411

PISTON

18

707-44-12180

RING,PISTON (KIT)

19

707-39-12110

RING,WEAR (KIT)

20

707-44-12911

RING

21

707-71-60901

PLUNGER

22

07165-15860

NUT

23

707-71-32640

COLLAR

24

07001-05115

RING,BACK-UP

25

07000-15115

O-RING (KIT)

26

20Y-63-52372

TUBE,L.H.

|26

20Y-63-52472

TUBE,R.H.

27

07372-21060

BOLT

28

07372-21045

BOLT

29

01643-51032

WASHER

30

07000-13030

O-RING (KIT)

31

20Y-63-52390

BRACKET,L.H.

|31

20Y-63-52490

BRACKET,R.H.

32

707-88-96530

BAND

33

01010-81035

BOLT

34

01643-51032

WASHER

35

07283-22738

CLIP

36

01599-01011

NUT

37

01643-31032

WASHER
