Запчасти Komatsu PC210LC-6K ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№K-K999) ГИДРАВЛИКА
1
2
3
4
5
5
6
7
8
9
9
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
32
33
34
34
35
№
Артикул
Название
Примечание
Количество
|1
723-48-10701
CONTROL VALVE
|1
723-48-10700
CONTROL VALVE
|1
723-40-66300
VALVE ASS'Y
1
CASE
2
SEAT
3
SEAT
4
BALL
5
PLUG
|6
723-46-40100
VALVE ASS'Y
6
SLEEVE
7
PISTON SUB ASS'Y
8
SPRING
9
SEAL
10
700-93-11320
O-RING
11
723-46-41950
RING
12
07002-13634
O-RING
|13
709-70-74600
VALVE ASS'Y,SUCTION AND SAFETY
|13
709-70-74402
VALVE ASS'Y
13
SLEEVE
14
SLEEVE
15
POPPET
16
PISTON
17
PLUG
18
POPPET
19
SCREW
20
SPRING
21
SPRING
22
SPRING
23
SEAL
24
SEAL
25
709-25-11390
O-RING
26
O-RING
27
O-RING
28
NUT
|29
723-46-40500
VALVE ASS'Y
29
SLEEVE
30
VALVE
31
SPRING
32
SEAL
33
700-93-11320
O-RING
34
723-46-41950
RING
35
07002-13634
O-RING
Выбрано товаров: 42
