Запчасти Komatsu PC210LC-6K ОСНОВН. КЛАПАН (-АКТУАТОР) (7/)(№K-K999) ГИДРАВЛИКА

Схема запчастей Komatsu PC210LC-6K - ОСНОВН. КЛАПАН (-АКТУАТОР) (7/)(№K-K999) ГИДРАВЛИКА
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56

Артикул

Название

Примечание

Количество

|1

723-47-10701

CONTROL VALVE

|1

723-47-10401

CONTROL VALVE

|1

723-47-10400

CONTROL VALVE

|1

723-40-50100

VALVE ASS'Y

1

SLEEVE

2

PLUG

3

PLUG

4

VALVE

5

PISTON

6

RETAINER

7

SPRING

8

POPPET

9

PISTON

10

SPRING

11

SLEEVE

12

RETAINER

13

NUT

14

SLEEVE

15

PISTON

16

700-80-61260

O-RING

17

700-80-61430

RING

18

07000-12021

O-RING

19

07001-02021

RING,BACK-UP

20

07002-13034

O-RING

21

O-RING

22

O-RING

23

RING,BACK-UP

24

07000-03032

O-RING

25

O-RING

26

SEAL

|27

723-40-50200

VALVE ASS'Y

27

SLEEVE

28

VALVE

29

POPPET

30

SPRING

31

SCREW

32

SPRING

33

RING

34

NUT

35

700-22-11410

O-RING

36

700-80-64220

RING

37

07002-02434

O-RING

38

O-RING

|39

723-40-50201

VALVE ASS'Y

39

SLEEVE

40

SEAT

41

VALVE

42

POPPET

43

SPRING

44

HOLDER

45

SCREW

46

SPRING

47

PLUG

48

NUT

49

NUT

50

700-22-11410

O-RING

51

700-80-64220

RING

52

07002-02434

O-RING

53

O-RING

54

O-RING

55

RING

56

O-RING

Выбрано товаров: 62
