Запчасти Komatsu PC210LC-10 СИСТЕМА ОХЛАЖДЕНИЯ, ЗАЩИТА ВЕНТИЛЯТОРА (№-) СИСТЕМА ОХЛАЖДЕНИЯ

1

2A5-03-13831

Guard

2

01010-81030

Bolt

3

01643-31032

Washer

4

2A5-03-13841

Guard

5

01010-81030

Bolt

6

01643-31032

Washer

7

2A5-03-13851

Bracket

8

01010-81030

Bolt

9

01643-31032

Washer

10

2A5-03-13670

Tube

11

01010-81245

Bolt

12

01643-31232

Washer

13

2A5-03-13680

Tube

14

01010-81245

Bolt

15

01643-31232

Washer

16

07283-34346

Clip

17

01643-31032

Washer

18

01597-01009

Nut

19

07000-13045

O-ring

20

07040-11409

Plug

21

07002-11423

O-ring

22

2A5-03-13880

Plate

23

01010-81030

Bolt

24

01643-31032

Washer

25

6738-11-4320

Pipe

26

07043-70108

Plug

27

6738-11-4370

O-ring

28

6738-11-4380

Clamp

29

6738-11-4390

Nut

30

2A5-03-13361

Hose

31

04434-51612

Clip

32

04435-51612

Clip

33

01010-81275

Bolt

34

01643-31232

Washer

35

14X-54-26640

Collar

36

11Y-09-11140

Clip

|$36

2A5-03-11791

Cover

37

Cover

38

2A5-03-11780

Sheet

39

01010-81020

Bolt

40

01643-31032

Washer

40

2A5-03-13341

Cover Assembly

41

Cover

42

2A5-03-13371

Sheet

43

01010-81030

Bolt

44

01643-31032

Washer

45

2A5-03-13810

Cover

46

01010-81230

Bolt

47

01643-31232

Washer

48

2A5-03-13861

Sheet

49

2A5-03-11870

Sheet

50

2A5-03-13890

Sheet

51

2A5-03-13920

Sheet

52

2A5-03-11930

Sheet

53

2A5-03-13521

Sheet

54

2A5-03-13951

Sheet
