Запчасти Komatsu PC210-8K 2-СЕКЦИОНН. СТРЕЛА (1-Я СТРЕЛА АВТОМАТИЧ. СМАЗ.) G АВТОМАТИЧ. СМАЗ. СИСТЕМА

1

20Y-62-K7540

FITTING

2

20Y-62-K7530

FITTING

3

20Y-62-K7520

UNION

4

20Y-62-K7480

BLOCK

5

20Y-62-K7870

BRACKET

|6

20Y-70-K5210

HOSE ASSEMBLY

6

20Y-70-K5220

HOSE (400MM)

7

203-62-57940

MARK, 4

8

20Y-70-K5230

HOSE (450MM)

9

203-62-57980

MARK, 8

10

20Y-70-K5240

HOSE (500MM)

11

203-62-57930

MARK, 3

12

20Y-70-K5250

HOSE (550MM)

13

203-62-57950

MARK, 5

14

20Y-70-K5260

HOSE (600MM)

15

01010-81020

BOLT

16

01643-31032

WASHER

17

01010-81025

BOLT

18

01643-31032

WASHER

19

207-70-K3040

CLAMP

20

20Y-62-K8581

CLAMP

21

207-70-K3260

BRACKET

22

20Y-62-K9431

BRACKET

23

07283-32746

CLIP

24

07283-52737

SEAT

25

01643-31032

WASHER

26

01597-01009

NUT

27

20Y-70-K5151

TUBE

28

20Y-70-K5141

TUBE

29

20Y-70-K5160

TUBE

30

20Y-70-K5170

TUBE

31

20Y-62-13450

PLATE

32

20Y-06-K2770

SPACER

33

04434-52112

CLIP

34

01010-81280

BOLT

35

01643-31232

WASHER

36

04434-51012

CLIP

37

04435-51010

CLIP

38

04435-50812

CLIP

39

04435-51012

CLIP
