Запчасти Komatsu PC210-8K ЦИЛИНДР РУКОЯТИ(ДЛЯ КЛАПАНА ПЕРЕГРУЗКИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-0R081

CYLINDER GROUP

|$2

707-01-0R080

CYLINDER GROUP

|1

707-01-0H601

CYLINDER ASSEMBLY

|1

707-01-0H600

CYLINDER ASSEMBLY

1

707-13-13870

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL, DUST (KIT)

|3

707-77-80010

SEAL, DUST (KIT)

4

707-58-95270

ROD, PISTON

5

707-27-13850

HEAD, CYLINDER

6

07179-13109

RING, SNAP

7

707-56-95510

SEAL, DUST (KIT)

|7

707-56-95730

SEAL, DUST (KIT)

8

707-52-90721

BUSHING

|8

707-52-90720

BUSHING

9

707-75-95030

RING, SNAP

10

707-51-95030

PACKING, ROD (KIT)

11

07000-15125

O-RING (KIT)

12

707-35-31260

RING, BACK-UP (KIT)

|12

707-35-91370

RING, BACK-UP (KIT)

13

707-51-95650

RING, BUFFER (KIT)

14

01010-81875

BOLT

15

707-41-11840

WASHER

16

707-36-13771

PISTON

17

707-44-13250

RING, PISTON (KIT)

18

707-39-13530

RING, WEAR (KIT)

19

707-44-13920

RING

20

707-71-71010

PLUNGER

|20

707-71-71070

PLUNGER

21

07000-15085

O-RING (KIT)

22

707-35-30850

RING, BACK-UP (KIT)

|22

707-35-90960

RING, BACK-UP (KIT)

23

01310-01216

SCREW

24

707-71-80270

PLUNGER

25

07020-00000

FITTING, GREASE

26

707-71-34980

COLLAR

27

707-35-31260

RING, BACK-UP (KIT)

|27

707-35-91370

RING, BACK-UP (KIT)

28

07000-15125

O-RING (KIT)

29

04260-00635

BALL

30

707-71-91270

CAP

31

707-83-13010

VALVE

32

07750-01628

SPRING

33

707-87-14070

PLUG

34

07002-12034

O-RING (KIT)

35

707-88-33040

CAP

36

07371-31049

FLANGE, SPLIT

37

07372-21035

BOLT

38

01643-51032

WASHER

39

707-88-33030

HEAD

40

07371-30640

FLANGE, SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|K

707-99-50500

SERVICE KIT

|$57

707-98-48610

SERVICE KIT
