Запчасти Komatsu PC210-8K ОСНОВН. НАСОС (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2L-00701

PUMP ASSEMBLY

|1

708-2L-00700

PUMP ASSEMBLY

|1

708-2L-01701

PUMP SUB ASSEMBLY

|1

708-2L-01700

PUMP SUB ASSEMBLY

1

708-2L-42210

SHAFT, FRONT

2

708-2L-42250

BEARING

3

708-2E-05040

WASHER KIT

|3

WASHER, 3.1MM

|3

WASHER, 3.0MM

|3

WASHER, 2.9MM

|3

WASHER, 2.8MM

4

708-25-12790

RING, SNAP

5

708-25-52861

SEAL, OIL

6

708-2L-22160

SPACER

7

04065-06825

RING, SNAP

|8

708-2L-06590

BLOCK ASSEMBLY, FRONT

8

BLOCK, CYLINDER

9

PLATE, VALVE

10

708-18-13230

PIN

11

04065-05820

RING, SNAP

12

708-2L-43130

SEAT

13

708-2L-43150

SPRING

14

708-2H-23141

SEAT

15

708-2L-43510

GUIDE, RETAINER

16

708-2L-43360

PIN

17

708-2L-43340

RETAINER, SHOE

18

708-2L-43311

PISTON SUB ASSEMBLY

|19

708-2L-06262

CRADLE ASSEMBLY

19

CRADLE

20

CAM, ROCKER

21

04020-01228

PIN, DOWEL

22

01252-61025

BOLT
