Запчасти Komatsu PC210-8K РУКОЯТЬ (.9M) (2-СЕКЦИОНН. СТРЕЛА) (№K9-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20Y-944-K492

ARM

1

20Y-70-K4562

ARM

2

20Y-970-3570

BRACKET (WELDED)

3

20J-70-12180

SEAT (WELDED)

4

206-62-K2740

BRACKET (WELDED)

5

20Y-62-K7290

SEAT (WELDED)

6

20Y-70-31272

BUSHING

7

20Y-70-32410

BUSHING

8

205-70-73180

BUSHING

9

07145-00090

SEAL

10

20Y-70-23220

SEAL

11

20Y-70-23230

SEAL

12

20Y-70-31160

PIN

13

20Y-62-K7651

PLATE

|13

20Y-62-K7650

PLATE

14

01010-81240

BOLT

|14

01010-81230

BOLT

15

01643-31232

WASHER

16

21K-70-71650

SPACER, 1.0MM

|16

20Y-70-31431

SPACER, 1.0MM

17

205-70-71190

PIN

18

205-70-66580

PLATE

19

01010-81230

BOLT

20

01643-31232

WASHER

21

21K-70-71630

SPACER, 1.0MM

|21

20Y-70-31381

SPACER, 1.0MM

22

21K-70-71640

SPACER, 2.0MM

|22

20Y-70-31391

SPACER, 2.0MM

23

707-01-XR270

CYLINDER GROUP

|23

707-01-XJ270

CYLINDER GROUP
