Запчасти Komatsu PC210-7K ЦИЛИНДР РУКОЯТИ(С КЛАПАН ПЕРЕГРУЗКИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XX281

ARM CYLINDER GROUP,(WITH BURST VALVE)

G1

707-01-XX280

ARM CYLINDER GROUP,(WITH BURST VALVE)

|1

707-01-0A311

CYLINDER ASS'Y,(WITH BURST VALVE)

|1

707-01-0A310

CYLINDER ASS'Y,(WITH BURST VALVE)

1

707-13-13540

CYLINDER

2

707-76-80470

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-95162

ROD,PISTON

|4

707-58-95161

ROD,PISTON

5

707-76-80470

BUSHING

6

07145-00080

SEAL (KIT)

7

707-27-13961

HEAD,CYLINDER

8

07179-13109

RING,SNAP

9

707-56-95510

SEAL,DUST (KIT)

10

707-52-90720

BUSHING

11

707-51-95030

PACKING,ROD (KIT)

12

07000-15125

O-RING (KIT)

13

707-35-91370

RING,BACK-UP (KIT)

14

707-51-95640

RING,BUFFER (KIT)

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-13771

PISTON

18

707-44-13280

RING,PISTON (KIT)

19

707-39-13530

RING,WEAR (KIT)

20

707-44-13920

RING

21

707-71-61070

PLUNGER

22

07000-15085

O-RING (KIT)

23

707-35-90960

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

707-71-70270

PLUNGER

26

07020-00000

FITTING,GREASE

27

707-71-32770

COLLAR

28

707-35-91370

RING,BACK-UP (KIT)

29

07000-15125

O-RING (KIT)

30

04260-00635

BALL

31

707-71-91270

CAP

32

707-83-13010

VALVE

33

07750-01628

SPRING

34

707-87-14070

PLUG

35

07002-12034

O-RING (KIT)

36

707-88-33030

HEAD

37

07371-30640

FLANGE

38

707-88-33040

CAP

39

07371-31049

FLANGE

40

07372-21035

BOLT

41

01643-51032

WASHER

K

707-99-57160

SERVICE KIT
