Запчасти Komatsu PC210-7K ТАБЛИЧКИ (АНГЛ.) (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) (STD) МАРКИРОВКА

Схема запчастей Komatsu PC210-7K - ТАБЛИЧКИ (АНГЛ.) (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) (STD) МАРКИРОВКА
1
2
3
4
5
5
6
6
7
8
8
9
10
11
12
13
14
15
15
16
16
16
17
18
19
20
20
20
20
20
21
21
21
22
22
23
24
25
26
27
28
29
30
30
31
32
33
34
35
36
37
38
38
39
39A
40

Артикул

Название

Примечание

Количество

|1

20Y-00-38211

DECAL KIT

|1

20Y-00-38240

DECAL KIT

1

09685-00002

PLATE¤ OPERATING,SAFETY LOCK LEVER

2

09690-M0063

PLATE¤ MARK,KOMATSU

3

09690-P0630

PLATE¤ MARK,KOMATSU (BATTERY CASE)

4

20E-00-K1140

PLATE¤ CAUTION,KEEP OFF WORKING AREA

5

20Y-00-K2680

PLATE¤ MARK,PC210

6

09653-A0481

PLATE¤ SAFETY,RADIATOR CAP AND OIL INLET

7

09669-0000E

PLATE¤ CAUTION,FUEL INLET

|7

09669-0000B

PLATE¤ CAUTION,FUEL INLET

8

20E-00-K1150

PLATE¤ CAUTION,KEEP OFF SWING AREA

9

206-00-K1010

PLATE,SWING AND PUMP OVERRIDE

10

207-00-71360

PLATE,FUSE

11

207-00-K1951

PLATE,WARNING DECAL

12

09803-A0481

PLATE¤ SAFETY,WINDOW LOCK

13

09805-C0481

PLATE¤ SAFETY,HOOD

14

20Y-00-K2611

CHART¤ LUBRICATION

15

09657-A0881

PLATE¤ SAFETY,TRACK ADJUSTMENT WARNING

16

09659-A057B

PLATE¤ SAFETY,ACCUMULATOR AND GAS SPRING

17

09669-0000C

PLATE¤ CAUTION,HYDRAULIC OIL INLET

18

09963-A1640

TAG,DO NOT OPERATE

19

20Y-00-38150

PLATE¤ CAUTION,OVERLOAD

|19

20Y-00-38110

PLATE¤ CAUTION,OVERLOAD

20

203-00-51170

SEAT,NON SLIP

21

154-54-23260

SEAT,NON SLIP

22

20Y-00-31110

SHEET,NON SLIP

23

09667-A0481

PLATE¤ SAFETY,KEEP AWAY FAN AND BELT

24

09805-A0881

PLATE¤ SAFETY,KEEP AWAY FROM EDGE

25

09808-A0881

PLATE¤ SAFETY,BATTERY CABLE

26

20Y-00-K2220

PLATE,EMERGENCY EXIT

27

09690-P1250

PLATE¤ MARK,KOMATSU (BOOM)

28

09690-P1250

PLATE¤ MARK,KOMATSU (COUNTER WEIGHT)

29

20Y-00-K2640

PLATE,LIFTING

30

21U-98-31150

PLATE¤ MARK,LIFTING POINT

31

20E-00-K1120

PLATE¤ INSTRUCTION,AIR CLEANER ELEMENT

32

205-00-73360

PLATE¤ OPERATING,OIL LEVEL

33

09696-50071

PLATE,NOISE¤ OPERATOR

34

09696-40104

PLATE,DYNAMIC NOISE

35

20Y-00-K2380

PLATE,RECOMMENDED LUBRICANT

36

20E-00-K1710

PLATE¤ CAUTION,BLUE TAG

37

20E-00-K1690

PLATE¤ CAUTION,ANTI-FREEZE

38

20E-00-K1260

PLATE¤ MARK,ZEBRA

39

20Y-00-38120

PLATE,LIFTING CAPACITY TABLE

|39

20Y-00-38130

PLATE,LIFTING CAPACITY TABLE

39A

207-00-K1770

PLATE

40

205-00-K1291

PLATE¤ NAME,(LIMITED SUPPLY)

|40

205-00-K1290

PLATE¤ NAME,(LIMITED SUPPLY)

Выбрано товаров: 47
