Запчасти Komatsu PC210-6G ГУСЕНИЦЫ () (MM ШИР.) ХОДОВАЯ

Схема запчастей Komatsu PC210-6G - ГУСЕНИЦЫ () (MM ШИР.) ХОДОВАЯ
1
2
3
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
19
19
19
20
20

Артикул

Название

Примечание

Количество

|1

20Y-32-01054

TRACK SHOE ASS'Y

|1

20Y-32-01053

TRACK SHOE ASS'Y

1

20Y-32-11123

LINK,TRACK¤ L.H.

2

20Y-32-11133

LINK,TRACK¤ R.H.

3

20Y-32-11240

SEAL,DUST¤ REGULAR¤ W-TYPE

4

20Y-32-11171

BUSHING¤ MASTER

|4

20Y-32-11170

BUSHING¤ MASTER

5

20Y-32-11141

BUSHING¤ REGULAR

|5

20Y-32-11140

BUSHING¤ REGULAR

6

20Y-32-11150

PIN¤ REGULAR

7

20Y-32-11350

SHOE,TRACK

8

20Y-32-11220

BOLT¤ SHOE (Y0320-K02

9

154-32-31220

NUT¤ SHOE (Y0320-K02

10

20Y-32-11123

LINK,TRACK¤ L.H.

11

20Y-32-11133

LINK,TRACK¤ R.H.

12

20Y-32-11240

SEAL,DUST¤ REGULAR¤ W-TYPE

13

20Y-32-11171

BUSHING¤ MASTER

|13

20Y-32-11170

BUSHING¤ MASTER

14

20Y-32-11141

BUSHING¤ REGULAR

|14

20Y-32-11140

BUSHING¤ REGULAR

15

20Y-32-11150

PIN¤ REGULAR

16

20Y-32-11350

SHOE,TRACK

17

20Y-32-11220

BOLT¤ SHOE (Y0320-K02

18

154-32-31220

NUT¤ SHOE (Y0320-K02

19

20Y-32-11260

SEAL,DUST¤ MASTER¤ W-TYPE

20

20Y-32-11190

PIN¤ MASTER

Выбрано товаров: 26
