Запчасти Komatsu PC210-6G РАБОЧАЯ ЛИНИЯ PPC (ЛИНИЯ КЛАПАНА EPC) (EPC)(№9-979) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-62-22771

HOSE¤ 700MM

2

20Y-62-22790

BAND¤ RED

3

20Y-62-23831

HOSE¤ 800MM

4

20Y-62-22810

BAND

5

20Y-62-23831

HOSE¤ 800MM

6

20Y-62-22820

BAND¤ BLUE

7

20Y-62-22781

HOSE¤ 650MM

8

20Y-62-22830

BAND¤ WHITE

9

20Y-62-22781

HOSE¤ 650MM

10

20Y-62-22840

BAND

11

20Y-62-22771

HOSE¤ 700MM

12

20Y-62-22850

BAND¤ GREEN

13

20Y-62-22721

HOSE¤ 535MM

14

20Y-62-22860

BAND¤ BROWN

15

20Y-62-22721

HOSE¤ 535MM

16

20Y-62-23510

HOSE¤ 1200MM

17

07102-20319

HOSE

18

20Y-62-22291

CLAMP

19

01010-81230

BOLT

20

01643-31232

WASHER

21

20Y-62-22890

HOSE¤ 2950MM

22

20Y-62-22790

BAND¤ RED

23

20Y-62-22910

HOSE¤ 1050MM

24

20Y-62-23480

HOSE¤ 1450MM

25

20Y-62-22820

BAND¤ BLUE

26

20Y-62-22190

CLAMP

27

04435-51608

CLIP

28

01010-80816

BOLT

29

01643-30823

WASHER

30

20Y-62-22151

BLOCK

31

01010-81050

BOLT

32

01643-31032

WASHER

33

07235-10315

ELBOW

34

07002-02034

O-RING

35

207-62-33920

ELBOW

36

07002-01423

O-RING

37

07230-20210

UNION

38

07040-11409

PLUG

39

07002-01423

O-RING

40

20Y-62-22210

BRACKET

41

01010-81016

BOLT

42

01643-31032

WASHER

43

08036-01414

CLIP

44

01010-81230

BOLT

45

01643-31232

WASHER

46

08034-00519

BAND
