Запчасти Komatsu PC210-10 ДВЕРЬ ЛЕВ., (/) ДВЕРЬ ЛЕВ.

1

206-54-31161

Frame

2

2A5-54-15810

Frame

3

2A5-54-11721

Frame

|$3

2A5-54-15641

Cover

5

2A5-54-15880

Sheet

6

01010-81230

Bolt

7

01643-31232

Washer

8

01010-81250

Bolt

9

01643-31232

Washer

10

2A5-54-15111

Cover

11

01010-81230

Bolt

12

01643-31232

Washer

13

2A5-54-15120

Cover

14

20Y-54-63414

Hinge, Welded

15

20Y-54-71372

Lock, Welded

16

20Y-54-73752

Sheet

17

20Y-54-73841

Sheet

18

2A5-54-14490

Sheet

19

124-54-26540

Washer

20

01010-81225

Bolt

21

20Y-54-61470

Plate

22

01010-81225

Bolt

23

01643-31232

Washer

24

205-54-53550

Dovetail

25

01010-80612

Bolt

26

01643-30623

Washer

27

20Y-54-28170

Bracket

28

01010-81225

Bolt

29

01643-31232

Washer

30

205-54-51971

Dovetail

31

01010-80616

Bolt

32

01643-30623

Washer

33

20Y-54-11611

Stopper

34

01580-11008

Nut

35

2A5-54-11771

Sheet

36

2A5-54-11791

Sheet

37

2A5-54-11781

Sheet

38

2A5-54-15130

Cover

39

20Y-54-63414

Hinge, Welded

40

2A5-54-14350

Sheet

41

2A5-54-14360

Sheet

42

124-54-26540

Washer

43

01010-81225

Bolt

44

2A5-54-12941

Bracket

45

01010-81230

Bolt

46

01643-31232

Washer

47

2A5-54-11960

Yoke

48

2A5-54-15981

Damper

49

04205-30825

Pin

50

01640-20816

Washer

51

04052-20833

Pin

52

206-54-31150

Plate

53

203-54-63230

Clamp

54

01023-10616

Screw

55

01010-81230

Bolt

56

01643-31232

Washer

57

206-54-11120

Bracket

58

01010-81230

Bolt

59

01643-31232

Washer
