Запчасти Komatsu PC20UU-3 ГИДРОМОЛОТ (ВНУТР. ЧАСТИ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20C-970-2201

BREAKER ASS'Y

1

20C-970-1120

CYLINDER

2

21U-970-1110

SEAL,DUST

3

21U-970-1120

U-PACKING

4

21U-970-1130

RETAINER,SEAL

5

21U-970-1140

U-PACKING

6

21U-970-1410

U-PACKING

7

21U-970-1150

O-RING

8

21U-970-1160

PLUG

9

21U-970-1170

O-RING

10

21U-970-1180

PLUG

11

21U-970-1190

O-RING

12

21U-970-1200

PLUG

13

21U-970-1210

O-RING

14

21U-970-1220

PLUG

15

21U-970-1230

PISTON

16

21U-970-1240

VALVE

17

20C-973-1130

HEAD,FRONT

18

21U-970-1260

BUSHING,FRONT

19

21U-970-1270

BUSHING,THRUST

20

21U-970-1280

RING,SNAP

21

07144-10303

BUSHING

22

07145-00030

SEAL,DUST

23

21U-970-1290

PIN,STOP

24

21U-970-1300

PIN,SPRING

25

21U-970-1310

NIPPLE,GREASE

26

21U-970-1320

PIN,ROD

27

21U-970-1330

PIN,RING

28

21U-970-1360

HEAD,BACK

29

21U-970-1370

VALVE,CHARGING

30

21U-970-1380

BOLT,THROUGH

31

21U-970-1390

NUT

32

21U-970-1400

WASHER

33

20C-970-1110

PLATE

34

20P-970-7160

CHISEL

35

21U-970-2181

DUMMY CHISEL

|36

21U-970-1430

ACCESSORY ASS'Y

36

21U-970-1440

CASE,WRENCH

37

21U-970-1450

BOMB,CHARGING

38

21U-970-1460

HOLDER,CHARGING

39

21U-970-1470

ADAPTER,CHECK

40

21U-970-1480

GAUGE,PRESSURE

K

21U-970-1490

SEAL KIT

|K1

21U-970-1110

SEAL,DUST

|K1

21U-970-1120

U-PACKING

|K1

21U-970-1400

WASHER

|K1

21U-970-1410

U-PACKING

|K1

21U-970-1150

O-RING

|K1

21U-970-1370

VALVE,CHARGING
