Запчасти Komatsu PC20R-8 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

\0

871070021

MOTOR, ASSY.

1

YM23065-160800

PIPE

2

YM124736-07900

LIFTER

3

YM26106-080142

BOLT

4

YM119812-11700

HEAD,ASSY.

5

HEAD, ASSY.

7

YM124060-11800

GUIDE VALVE

9

YM26216-060302

STUD

10

YM27241-400000

PLUG

11

YM119810-11100

VALVE, INLET

12

YM119810-11110

VALVE EXHAUST

13

YM119810-11120

SPRING, VALVE

14

YM104211-11180

RETAINER, SPRING

15

YM27310-070000

COTTER

16

YM124160-11340

SEAL, VALVE STEM

17

YM124950-11340

SEAL, VALVE EXHAUST

18

YM104211-11370

CAP VALVE

19

YM22351-060012

PEG

20

YM119865-11210

ROCKER SHAFT, ASSY.

21

YM119810-11240

ROCKER SHAFT

24

YM129155-11260

SUPPORT

25

YM129155-11270

SUPPORT

26

YM129150-11280

SPRING

27

YM719810-11660

ROCKER SHAFT

28

YM129150-11230

SCREW

30

YM129150-11750

NUT

31

YM26226-080182

STUD

32

YM119625-11870

PROTECTION, NOZZLE

33

YM119625-11880

SEAT, NOZZLE

34

YM119625-11900

RETAINER

35

YM26106-080252

SCREW

36

YM26106-080502

SCREW

37

YM26366-060002

NUT

38

YM719810-11520

BONNET ASSY., HEAD

39

YM124160-01751

CAP, LUB. OIL SUPPLY

40

YM129150-03020

COVER, BREATHER

41

YM129150-03070

SPLASH-GUARD

42

YM129150-03080

PROTECTION

44

YM119865-11310

GASKET

45

YM24311-000320

O-RING

46

YM24341-000500

O-RING

47

YM26106-080162

BOLT

48

YM124160-11360

PLUG

49

YM24311-000120

O-RING
