Запчасти Komatsu PC20MR-3 ГИДР. БАК. (№-) ГИДР. БАК.

1

22K-60-32111

Tank, Hydraulic Oil

2

07044-12412

Plug

3

07002-12434

O-ring

4

21U-60-32121

Strainer

5

07000-12085

O-ring

6

01010-81025

Bolt

7

01643-31032

Washer

8

209-60-51180

Cap Assembly

9

22K-60-22170

Plate

10

01010-81020

Bolt

11

01643-31032

Washer

12

07270-00885

Tube

13

07285-00095

Clip, Hose

14

22L-60-22161

Tube

14

203-60-31100

Elbow Assembly

15

Elbow

16

Nut

17

203-60-31250

Sleeve

18

203-00-31120

Plate, Instruction

19

22L-60-22212

Flange

20

22L-60-22120

Element, Hydraulic Oil Filter

21

22L-60-22130

Valve Assembly

22

22L-60-22140

Spring

23

07000-12120

O-ring

24

01010-81025

Bolt

25

01643-31032

Washer

26

22K-60-22121

Case

27

07000-12125

O-ring

28

20M-62-82271

Nipple

29

07002-12434

O-ring

29

22K-60-22500

Valve Assembly

30

Union

31

198-15-15770

Spring, L=30mm

32

Poppet

33

22K-60-22240

Seat

34

04065-01410

Ring

35

07002-12434

O-ring

36

02896-11015

O-ring

37

22L-60-22180

Cushion

38

22K-60-22181

Cushion

39

22K-60-22191

Sheet

40

02896-11009

O-ring

41

02896-11008

O-ring

42

01010-81025

Bolt

43

01643-31032

Washer

44

22K-60-32120

Cushion

45

22K-60-32311

Bracket

46

22K-60-32321

Sheet

47

22K-60-32330

Sheet

48

22K-60-32341

Sheet

49

20C-43-32170

Seal

50

01010-80612

Bolt

51

01643-30623

Washer
