Запчасти Komatsu PC20MR-2 ЛЕВ. СЕРВОУПРАВЛ. (НАВЕС) СИСТЕМА УПРАВЛЕНИЯ И ОСНОВНАЯ РАМА

1

22M-43-21291

STOPPER

2

01010-D0820

BOLT

3

01643-10823

WASHER

4

22M-43-R1551

GUIDE

5

04205-10830

PIN

6

04050-12015

PIN, COTTER

7

21U-43-32430

BUSHING

8

22B-54-15560

STOPPER

9

01580-11008

NUT

10

22M-43-21111

HOUSING

11

22M-54-22140

COVER

12

01252-70616

BOLT

13

01643-10623

WASHER

14

22M-43-21660

GAS SPRING

15

04205-30822

PIN

16

37A-09-4Z028

PIN, COTTER

17

01643-10823

WASHER

18

22M-43-21151

PIN

19

01010-D0612

BOLT

20

01643-10623

WASHER

21

22M-54-R2131

COVER

22

22M-43-21640

LEVER

\22

20Y-43-22620

KNOB

23

01370-10308

SCREW

24

20Y-43-22630

KNOB, L.H.

25

20Y-43-22421

INSERT

26

20Y-43-22250

COLLAR

27

20Y-43-22261

BOOT

28

20Y-43-22370

BOOT

29

600-411-1280

NUT

30

01252-71025

BOLT

31

01643-11032

WASHER

32

22M-43-R1541

LEVER, L.H.

33

06124-01616

BEARING, NEEDLE

34

22L-09-R3770

KNOB

35

37A-09-4P119

PIN, SPRING

36

22M-43-21560

SPRING

37

37A-09-4Z028

PIN, COTTER

38

01643-10823

WASHER

39

20T-54-81820

PLUG

39

22M-43-21170

SWITCH, ASSY.

40

37A-09-1W059

SCREW

41

01643-10623

WASHER
