Запчасти Komatsu PC20MR-2 МАРКИРОВКА (КАБИНА) (/) МАРКИРОВКА

Схема запчастей Komatsu PC20MR-2 - МАРКИРОВКА (КАБИНА) (/) МАРКИРОВКА
3
4
7
8
9
2
5
10
1
2
6
11
12
13
15
16
17
18
14
21
20
19
27
27
26
22
25
23
24
a
a
a
f
f
f
e
c
b
d
d
e
b
c

Артикул

Название

Примечание

Количество

1

09696-40093

MARK PLATE, LWA 93

2

22L-09-R4210

MARK PLATE, REFLEX REFLECTOR

3

22L-98-18270

PLATE, SAFETY EMERGENCY EXIT

4

22L-09-R4120

DECAL, DANGER, DO NOT OPEN ENGINE HOOD

5

22L-98-22270

DECAL, DANGER, KEEP OFF SWING AREA

6

22L-09-R2440

MARK PLATE

7

22K-98-21130

MARK PLATE, PC20MR-2, R.H.

8

42N-93-11510

MARK PLATE, UTILITY

9

22L-09-R4110

DECAL, DANGER, KEEP OUT WORKING AREA

10

09690-P0400

MARK PLATE, KOMATSU

11

22L-09-R4160

PLATE, LIFTING POINT

12

21D-98-11860

PLATE, ANCHOR POINT

13

21D-98-12050

DECAL, SYMBOL, HYDRAULIC OIL FILTER

14

21D-98-11230

DECAL, SYMBOL, HYDRAULIC OIL LEVEL

15

22F-98-33630

MARK PLATE, CAUTION, PRESSURISE THE TANK

16

22L-09-R4170

DECAL, SYMBOL, ENGINE COOLANT

17

21D-98-11150

DECAL, SYMBOL, RADIATOR CAP

18

09642-A0480

PLATE, INSTRUCTION, COOLANT

19

21S-98-33440

DECAL, SERVICE INSTRUCTION, AIR CLEANER

20

21D-98-11180

DECAL, SYMBOL, AIR FILTER

21

21D-98-12030

DECAL, SYMBOL, HYDRAULIC OIL

22

09651-A0481

DECAL, WARNING, READ MANUAL BEFORE OPERATING

23

22F-98-33640

PLATE, ENGINE OIL FILTER

24

21D-98-11190

DECAL, SYMBOL, ENGINE OIL FILTER

25

21D-98-11170

DECAL, SYMBOL, FUEL FILTER

26

6217-71-6860

DECAL, CAUTION, ENGINE FUEL FILTER

27

09659-A057B

PLATE, WARNING, ACCUMULATOR

Выбрано товаров: 27
