Запчасти Komatsu PC20MR-2 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

\0

22K-01-21101

TURBO ENGINE, ASSEMBLY

1

YM129900-07900

LIFTER

2

YM26106-080162

BOLT, FLANGED

3

YM129901-11450

PROTECTION

4

YM119600-11460

GASKET

5

YM105010-11490

PAD

6

YM119717-11740

HEAD ASSEMBLY, CYLINDER

13

YM119717-11800

GUIDE, VALVE

15

YM119285-11990

PLUG

16

YM23876-005000

PLUG

17

YM119717-11100

VALVE, SUCTION

18

YM119717-11110

VALVE, EXHAUST

19

YM119717-11131

SPRING, VALVE

20

YM129508-11180

RETAINER, SPRING

21

YM119717-11190

COTTER, ASSEMBLY

22

YM119717-11340

SEAL, VALVE STEM

23

YM119717-11350

SEAL, VALVE STEM

24

YM22351-060012

PIN, SPRING

25

YM119717-11200

SUPPORT, ASSEMBLY

26

YM119717-11240

ROCKER SHAFT, ASSEMBLY

29

YM119717-11260

RETAINER

30

YM119620-11280

SPRING

31

YM119717-11650

ROCKER ARM, ASSEMBLY

32

YM129150-11230

SCREW, VALVE

34

YM129150-11750

NUT

35

YM22242-000120

RING, SNAP

36

YM26979-050162

SCREW

37

YM26106-080402

BOLT, FLANGED

38

YM124160-01751

COVER, FILLER

39

YM119717-11381

COVER, HEAD, ASSY

40

YM119717-03031

PLATE

41

YM119717-03070

SPLASH-GUARD

42

YM119717-03070

SPLASH-GUARD

43

YM119802-03100

DIAPHRAGM, ASSEMBLY

44

YM119802-03110

RETAINER

45

YM119802-03121

COVER

46

YM119802-03131

DIAPHRAGM

47

YM119802-03141

SPRING

50

YM119718-11310

GASKET

51

YM119717-11320

COVER

52

YM119717-11331

GASKET

53

YM22857-500100

SCREW

54

YM22857-500100

SCREW

55

YM22857-500160

SCREW

56

YM24311-000320

O-RING

57

YM26106-060202

BOLT, FLANGED

58

YM26106-060752

BOLT

59

YM119717-77800

GLOW PLUG, ASSEMBLY

60

YM119717-77851

CONNECTOR

61

YM977770-01212

GASKET, LIQUID
