Запчасти Komatsu PC20MR-2 СТАРТЕР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC20MR-2 - СТАРТЕР ДВИГАТЕЛЬ
24
25
3
26
1
6
37
36
29
8
7
32
31
27
9
31
34
27
27
27
27
4
2
21
22
30
5
23
16
35
14
17
15
13
12
10
18
19
11
20
28
35
a
a
A

Артикул

Название

Примечание

Количество

\0

22K-01-21101

TURBO ENGINE, ASSEMBLY

1

YM119740-77020

STARTER MOTOR

2

YMX0283060061

ROLLER

3

YM129129-77460

SCREW

4

YMX9490561370

NUT

5

YMX9491200240

BALL

6

YM129407-77210

COIL, ASSEMBLY, FIELD

7

YM129407-77220

ROTOR, ASSEMBLY

8

YM129129-77230

BEARING

9

YM129129-77240

BEARING

10

YMX1280996680

KIT, STARTER

11

YMX0280210230

NUT

12

YMX0283270140

RETAINER

13

YM129129-77390

FAST COUPLING, ASSEMBLY

14

YM129129-77440

BEARING

15

YM129129-77450

BEARING

16

YM129129-77400

SHAFT

17

YM129129-77410

SPRING

18

YM129407-77410

SPRING

19

YMX0283712350

PINION

20

YM129129-77430

RING, SNAP

21

YM129129-77260

RETAINER

22

YM129129-77270

PINION

23

YMX4284003310

HOUSING

24

YM129407-77290

COVER

25

YM129407-77300

BRUSH HOLDER, ASSEMBLY

26

YMX9491730461

SPRING

27

YMX1534004151

SWITCH

28

YM129129-77320

BOLT

29

YM129407-77330

BOLT

30

YM129129-77340

SPRING

31

YM129129-77350

O-RING

32

YM129129-77362

COVER

34

YM129129-77380

BOOT

35

YM26106-100252

BOLT

36

YM22217-080000

SPRING WASHER

37

YM26756-080002

NUT

Выбрано товаров: 37
