Запчасти Komatsu PC20MR-2 ГИДР. БАК. РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

1

22K-60-R2112

HYDRAULIC TANK

2

22L-09-R1360

PLUG

3

07002-12434

O-RING

4

21U-60-32120

FILTER

5

07000-12085

O-RING

6

01010-81025

BOLT

7

01643-11032

WASHER

8

209-60-R1180

PLUG

9

22K-60-22170

PLATE

10

01010-81020

BOLT

11

01643-11032

WASHER

12

07270-00885

HOSE

13

07285-00095

CLIP, HOSE

14

22L-60-R2161

HOSE

15

22E-60-11120

ELBOW

16

01010-81025

BOLT

17

01643-11032

WASHER

18

22E-98-11230

PLATE, HYDRAULIC OIL LEVEL

19

22L-60-22212

FLANGE

20

22L-60-22120

ELEMENT, HYDRAULIC OIL FILTER

21

22L-60-R2130

VALVE, ASSEMBLY

22

22L-60-22140

SPRING

23

07000-12120

O-RING

24

01010-81025

BOLT

25

01643-11032

WASHER

26

22K-60-R2121

CASE

27

07000-12125

O-RING

28

22L-09-R4460

UNION

29

21D-09-69740

O-RING

\29

22K-60-22500

VALVE, ASSEMBLY

30

UNION

31

198-15-15770

SPRING, L=30MM

32

POPPET

33

22K-60-22240

SEAT

34

04065-01410

RING, SNAP

35

07002-12434

O-RING

36

02896-11015

O-RING

37

22L-60-22180

CUSHION

38

22K-60-22180

CUSHION

39

22K-60-22191

SHEET

42

02896-11008

O-RING

43

02896-11009

O-RING

44

22K-60-22310

BRACKET

45

22K-60-22320

SHEET

46

20C-03-21240

GASKET

47

01010-80610

BOLT

48

01643-10623

WASHER
