Запчасти Komatsu PC20MR-2-B ГИДР. БАК. ГИДРАВЛИКА

1

22K-60-22111

TANK

2

07044-12412

PLUG

3

07002-12434

O-RING

4

21U-60-32121

FILTER

5

07000-12085

O-RING

6

01010-81025

BOLT

7

01643-31032

WASHER

8

209-60-51180

CAP

9

22K-60-22170

PLATE

10

01010-81020

BOLT

11

01643-31032

WASHER

12

07270-00885

TUBE

13

07285-00095

CLIP

14

22L-60-22161

TUBE

|15

203-60-31100

ELBOW ASS'Y

15

ELBOW

16

NUT

17

203-60-31250

SLEEVE

18

203-00-31120

PLATE¤ INSTRUCTION

19

22L-60-22212

FLANGE

20

22L-60-22120

ELEMENT

21

22L-60-22130

VALVE ASS'Y

22

22L-60-22140

SPRING

23

07000-12120

O-RING

24

01010-81025

BOLT

25

01643-31032

WASHER

26

22K-60-22121

CASE

27

07000-12125

O-RING

28

20M-62-82271

NIPPLE

29

07002-12434

O-RING

|30

22K-60-22500

VALVE ASS'Y

30

UNION

31

198-15-15770

SPRING¤ (L= 30.0)

32

POPPET

33

22K-60-22240

SEAT

34

04065-01410

RING,SNAP

35

07002-12434

O-RING

36

02896-11015

O-RING

37

22L-60-22180

CUSHION

38

22K-60-22180

CUSHION

39

22K-60-22191

SHEET

40

01010-81025

BOLT

41

01643-31032

WASHER

42

02896-11008

O-RING

43

02896-11009

O-RING

44

22K-60-22310

BRACKET

45

22K-60-22320

SHEET

46

20C-03-21240

SEAL

47

01010-80612

BOLT

48

01643-30623

WASHER
