Запчасти Komatsu PC20MR-2-A ОСНОВН. НАСОС ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC20MR-2-A - ОСНОВН. НАСОС ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
33
34
34
35
36
37
38
39
40
40
41
41
42
42
43
43
43
43
44
44
45
46
47
48
49
50
51
52
53
54

Артикул

Название

Примечание

Количество

|1

22K-60-21301

PUMP ASS'Y

1

BODY

2

BODY

3

FUFZD4220103

SHAFT

|4

FUPKG100000

SERVICE KIT

4

BARREL,CYLINDER

5

PLATE,VALVE

|6

FUFZD412413

PISTON ASS'Y

6

PISTON

7

SHOE

8

HOLDER

9

HOLDER

10

NEEDLE

11

SPRING

12

FUPS29101000

RETAINER

13

RING,SNAP

14

FUFZD4220110

PLATE,SWASH

15

FUAL2033/4

PIN

16

PACKING (KIT)

17

FUFZD44351150A

SPRING

18

FUFZS4457118

HOLDER

19

FUFZD40201910A

GUIDE

20

FUPS13101000

PIN

21

FUFZD4220122

ROD

22

FUFZD4435126

SLEEVE

23

FUFZD4220127

PISTON

24

O-RING (KIT)

25

FU6205

BEARING

26

BEARING,NEEDLE

27

SEAL,OIL (KIT)

28

FURH52

RING,SNAP

29

FURA25

RING,SNAP

30

O-RING (KIT)

31

FUGPF1/4

PLUG

32

O-RING (KIT)

33

FUGPF1/8

PLUG

34

O-RING (KIT)

35

FUGPF1/2

PLUG

36

O-RING (KIT)

37

PIN,SPRING

38

FUFZD4197127

PIN

39

FUTH10X60

BOLT

40

FUTHSA8X35

SCREW

41

FUNHA8

NUT

42

FUWD8X16X2.0

WASHER (KIT)

43

FUTPUA1/16

PLUG

44

PLUG

45

708-1S-03830

VALVE ASS'Y,(SEE FIG.Y1679-01A0)

46

FUHL69118

CHOKE

47

FUFZD4220159

SEAT

48

705-41-02930

GEAR PUMP ASS'Y,(SEE FIG.Y1600-11A0)

49

FUFZD401916628

COUPLING

50

FUFZS2036731

COLLAR

51

FUTB8X20

BOLT

52

FUWGA8

WASHER

53

O-RING (KIT)

54

O-RING (KIT)

KIT

FUPKS100200

SEAL KIT

Выбрано товаров: 58
