Запчасти Komatsu PC200Z-6LE FIG NO. H-A ГИДР. БАК. БЕЗ ДАТЧИКА ГИДРАВЛИКА

1

20Y-60-22612

TANK

2

203-60-31100

ELBOW

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-02434

O-RING

6

07230-20628

UNION

7

07002-02434

O-RING

8

07236-10522

ELBOW

9

07002-02434

O-RING

10

07235-10315

ELBOW

11

07002-02034

O-RING

12

07236-10315

ELBOW

13

07002-02034

O-RING

14

07236-10210

ELBOW

15

07002-01423

O-RING

16

07235-10315

ELBOW

17

07002-02034

O-RING

18

20Y-60-21510

ELEMENT

19

206-60-41221

STRAINER

20

12R-60-11300

VALVE ASSEMBLY

21

20Y-60-21240

SPRING

22

20Y-60-22530

COVER

23

07000-05180

O-RING

24

01010-51230

BOLT

25

01643-31232

WASHER

26

20Y-60-11650

PLUG

27

7861-91-4220

O-RING

28

01010-80612

BOLT

29

01641-20608

WASHER

|$29

20Y-60-22550

STAINER ASSEMBLY

30

20Y-60-21311

STRAINER

31

207-60-61150

ROD ASSEMBLY

32

20Y-60-21320

HOLDER

33

12R-60-11230

SPRING

34

203-60-61140

COVER

35

07000-05180

O-RING

36

01010-81225

BOLT

37

01643-31232

WASHER

38

17A-60-11310

CAP ASSEMBLY

39

20Y-60-21470

ELEMENT

40

20Y-60-21460

NECK

41

205-60-66211

GASKET

42

01220-40516

SCREW

43

01601-20513

WASHER

44

07285-00155

CLIP

45

07270-61512

TUBE

46

20Y-60-22561

COVER

47

01220-40412

SCREW

48

20Y-60-22540

PLATE

49

01010-81635

BOLT

50

01643-31645

WASHER
