Запчасти Komatsu PC200Z-6LE ПРИВОД ВЕНТИЛЯТОРА ДВИГАТЕЛЬ

1

1310 375 H1

BELT, V

2

1310 376 H1

BOLT (M12x1.745x130)

3

1310 377 H1

BOLT (M10x1.50x25)

4

1310 378 H1

NUT, REGULAR HEXAGON (M10x1.50 Thd)

5

6736-21-3210

BOLT (M8x1.25x50)

6

1240 950 H1

BOLT (M8x1.25x80)

7

6732-61-3140

BOLT (M10x1.50x20)

|$7

3732-61-3120

SUPPORT, FAN

8

6732-61-3450

RING, RETAINING

9

6732-61-3440

BOLT (M10x1.50x70)

10

6732-61-3420

BEARING, BALL

11

6732-61-3410

HUB, FAN

12

NSS

SUPPORT, FAN

13

6732-61-3430

RETAINER, FAN HUB

14

6732-61-3750

PULLEY, FAN

15

1310 379 H1

BOLT (M10x1.50x30)

16

3732-61-3170

BOLT (M8x1.25x40)

17

1310 380 H1

PULLEY, FAN

18

1310 381 H1

PLATE, CLAMPING

19

1310 382 H1

BRACKET, BELT TENSIONER

20

1310 383 H1

BRACKET, ADJUSTING LINK

|$21

1310 384 H91

SUPPORT, FAN

21

1238 054 H1

RING, RETAINING

22

1310 385 H1

SUPPORT, FAN

23

1310 386 H1

BOSS

24

1310 387 H1

SHAFT, FAN HUB

25

1310 388 H1

BEARING, BALL

26

1310 389 H1

BEARING, BALL

N/I

1310 390 H1

COVER, ACCESS HOLE

|$29

1310 391 H91

SUPPORT, FAN

28

1310 392 H1

PULLEY, IDLER

29

1310 393 H1

SHAFT, IDLER

30

1310 394 H1

SPACER, MOUNTING

31

1310 395 H1

SUPPORT, BELT TENSIONER

32

1310 396 H1

BEARING, BALL

33

1310 397 H1

BEARING, BALL

34

1310 398 H1

COVER, ACCESS HOLE

35

1310 399 H1

RING, RETAINING

36

1310 400 H1

SPACER, MOUNTING

37

1310 401 H1

BOLT (M10x1.50x110)

38

1310 374 H1

WASHER, PLAIN
