Запчасти Komatsu PC200Z-6LE ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

1310 445 H91

HEAD, CYLINDER

1

NSS

HEAD, CYLINDER

2

1295 538 H2

PLUG, EXPANSION

3

6732-11-1930

PLUG, PIPE (1/8 NPT)

4

6732-11-1910

PLUG, PIPE (1/2 NPT)

|$5

1240 104 H92

VALVE, INTAKE

5

1240 127 H1

COLLET, VALVE

9

NSS

VALVE, INTAKE

|$8

1240 105 H92

VALVE, EXHAUST

5

1240 127 H1

COLLET, VALVE

10

NSS

VALVE, EXHAUST

6

1304 604 H1

SPRING, VALVE

7

1240 132 H1

RETAINER, VALVE SPRING

8

6732-41-4530

SEAL, VALVE STEM

8

6732-41-4540

SEAL, VALVE STEM

11

6732-11-1920

PLUG, PIPE (3/4 NPT)

12

1294 507 H2

BOLT (M12x1.75x70)

13

1294 508 H2

BOLT (M12x1.75x120)

14

6735-11-1811

GASKET,CYLINDER HEAD (STD)

|$17

1310 446 H1

GASKET,CYLINDER HEAD (.25 mm OVERSIZE)

|$18

1240 728 H4

GASKET,CYLINDER HEAD (.50 mm OVERSIZE)

15

1240 668 H1

INSERT, VALVE (EXHAUST)

16

1240 779 H1

INSERT, VALVE (INTAKE)

17

1240 677 H1

GUIDE, VALVE STEM - LONG INTAKE (THICK WALL)

18

1240 678 H1

GUIDE, VALVE STEM - LONG EXHAUST (THICK WALL)

19

1240 763 H1

GUIDE, VALVE STEM - INTAKE/EXHAUST (THIN WALL)
