Запчасти Komatsu PC200Z-6LE ТОПЛИВН. ТРУБЫ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC200Z-6LE - ТОПЛИВН. ТРУБЫ ДВИГАТЕЛЬ
5
22
4
20
6
23
2
19
11
4
12
15
16
18
21
11
12
9
18
12
9
13
8
14
13
12
1
14
14
12
11
9
9
12
13
17
3
13
7
14
8
13
10
10
13
13
13
8
8
14
14

Артикул

Название

Примечание

Количество

1

6732-71-6230

SEAL, BANJO CONNECTOR (6.2 MM)

2

6732-71-6240

SCREW, BANJO CONNECTOR (M6x1.00x14.3)

3

6732-11-4160

BOLT (M8x1.25x25)

4

07005-00812

WASHER, SEALING (8 MM)

5

6732-71-5690

VALVE, CHECK (M8x1.25x17.5)

6

6735-71-5150

MANIFOLD, FUEL

7

1310 301 H1

BRACE, TUBE

8

6734-71-5710

BRACE, TUBE

9

6735-71-5820

BRACE, TUBE

10

6735-71-5830

BRACE, TUBE

11

6735-71-5840

BRACE, TUBE

12

6735-71-5860

ISOLATOR, VIBRATION

13

6734-71-5720

ISOLATOR, VIBRATION

14

6734-71-5520

BOLT (M5x0.8x24.5)

15

1310 417 H1

TUBE, INJECTOR FUEL SUPPLY

16

1310 418 H1

TUBE, INJECTOR FUEL SUPPLY

17

1310 419 H1

TUBE, INJECTOR FUEL SUPPLY

18

1296 918 H1

ISOLATOR, VIBRATION

19

1310 420 H1

TUBE, INJECTOR FUEL SUPPLY

20

1310 421 H1

TUBE, INJECTOR FUEL SUPPLY

21

1310 423 H1

BRACE, TUBE

22

1310 422 H1

TUBE, INJECTOR FUEL SUPPLY

23

1310 424 H1

BRACE, TUBE

Выбрано товаров: 23
