Запчасти Komatsu PC200Z-6LE FIG NO. T- ЦИЛИНДР КОВША ДЛЯ .M И .9M РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

205-63-02130

CYLINDER ASSEMBLY, BUCKET

1

205-63-73340

CYLINDER

2

707-76-70110

BUSHING

3

07145-00070

SEAL, DUST

4

205-63-73320

ROD, PISTON

5

707-76-70120

BUSHING

6

21K-70-12180

SEAL, DUST

7

707-27-11680

HEAD, CYLINDER

8

07179-13094

RING, SNAP

9

195-63-92190

SEAL, DUST

10

707-52-90550

BUSHING

11

707-51-80030

PACKING, ROD

12

07000-15110

O-RING

13

07001-05110

RING, BACK-UP

14

707-51-80630

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-11510

PISTON

18

707-44-11280

RING, PISTON

19

707-39-11510

RING, WEAR

20

707-44-11920

RING

21

07165-15860

NUT

22

07020-00000

FITTING, GREASE

23

07020-00900

FITTING, GREASE

24

205-63-73370

TUBE

25

07372-21060

BOLT

26

07372-21045

BOLT

27

01643-51032

WASHER

28

07000-13030

O-RING

29

707-88-95370

BRACKET

30

707-88-95350

BAND

31

01010-51035

BOLT

32

01643-51032

WASHER

33

07282-02793

CLAMP

34

01010-51020

BOLT

35

01643-31032

WASHER

|$39

707-98-45220

SERVICE KIT, BUCKET CYLINDER

3

07145-00070

SEAL, DUST

6

21K-70-12180

SEAL, DUST

9

195-63-92190

SEAL, DUST

11

707-51-80030

PACKING, ROD

12

07000-15110

O-RING

13

07001-05110

RING, BACK-UP

14

707-51-80630

RING, BUFFER

18

707-44-11280

RING, PISTON

19

707-39-11510

RING, WEAR

28

07000-13030

O-RING
