Запчасти Komatsu PC200Z-6LE FIG NO. R- ГУСЕНИЦЫ ТРОЙНОЙ ГРУНТОЗАЦЕП. С ОТВЕРСТИЯМИ ХОДОВАЯ (ГУСЕНИЦЫ ТИП MACHINE)

|$0

20Y-32-01300

TRACK SHOE ASSEMBLY, 600 MM WIDE

|$1

20Y-32-00230

TRACK SHOE SUB-ASSEMBLY

|$2

20Y-32-00210

TRACK LINK SUB-ASSEMBLY

1

20Y-32-11123

LINK, L.H

2

20Y-32-11133

LINK, R.H

3

20Y-32-11240

SEAL, REGULAR DUST, W-TYPE

4

20Y-32-11170

BUSHING, MASTER

5

20Y-32-11140

BUSHING, REGULAR

6

20Y-32-11150

PIN, REGULAR

7

20Y-32-11111

SHOE, 600MM

8

20Y-32-11210

BOLT

9

154-32-31220

NUT

10

20Y-32-11260

SEAL, MASTER DUST, W-TYPE

11

20Y-32-11190

PIN, MASTER

|$15

20Y-32-01310

TRACK SHOE ASSEMBLY, 700 MM WIDE

|$16

20Y-32-00240

TRACK SHOE SUB-ASSEMBLY

|$17

20Y-32-00210

TRACK LINK SUB-ASSEMBLY

7

20Y-32-11311

SHOE, 700MM

8

20Y-32-11210

BOLT

9

154-32-31220

NUT

10

20Y-32-11260

SEAL, MASTER DUST, W-TYPE

11

20Y-32-11190

PIN, MASTER

|$24

20Y-32-01320

TRACK SHOE ASSEMBLY, 800 MM WIDE

|$25

20Y-32-00250

TRACK SHOE SUB-ASSEMBLY

|$26

20Y-32-00210

TRACK LINK SUB-ASSEMBLY

7

20Y-32-11311

SHOE, 800MM

8

20Y-32-11210

BOLT

9

154-32-31220

NUT

10

20Y-32-11260

SEAL, MASTER DUST, W-TYPE

11

20Y-32-11190

PIN, MASTER
