Запчасти Komatsu PC200Z-6LE FIG NO. K- ГИДРОЛИНИЯ АКТУАТОР PPC ЛИНИЯ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-62-27740

HOSE ASSEMBLY, R.H

1

20Y-62-23411

HOSE

2

20Y-62-23571

HOSE

3

203-62-52340

HOSE

4

203-62-52350

HOSE

5

20Y-62-22170

CLAMP

6

20Y-62-22790

BAND, RED

7

20Y-62-22810

BAND, YELLOW

8

20Y-62-22180

CLAMP

9

01010-81016

BOLT

10

01643-31032

WASHER

11

08034-00536

BAND

|$12

20Y-62-25541

HOSE ASSEMBLY, L.H

12

203-62-52350

HOSE

13

20Y-62-22881

HOSE

14

20Y-62-25551

HOSE

15

20Y-62-25561

HOSE

16

20Y-62-22170

CLAMP

17

20Y-62-22790

BAND, RED

18

20Y-62-22820

BAND, BLUE

19

20Y-62-22840

BAND, BLACK

20

20Y-62-22860

BAND, BROWN

21

20Y-62-22180

CLAMP

22

01010-81016

BOLT

23

01643-31032

WASHER

24

08034-00536

BAND

25

20Y-62-22220

BLOCK, ATTACHMENT PPC

26

01010-81010

BOLT

27

01643-31032

WASHER

28

08053-01512

CLIP

29

20Y-62-16630

NIPPLE

30

07002-01423

O-RING

31

20Y-62-22271

ELBOW

32

07002-01423

O-RING

33

14X-43-14840

ELBOW

34

07002-01423

O-RING

35

20Y-06-21710

SWITCH

36

20Y-06-22430

HARNESS, WIRING

37

203-62-58470

CLIP

38

01010-81225

BOLT

39

01643-31032

WASHER
