Запчасти Komatsu PC200Z-6LE FIG NO. K-C КАБИНА ПЕРЕДН. ОКНА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$1

201-54-73802

WINDOW ASSEMBLY, FRONT

1

201-54-73892

WINDOW, FRONT

2

201-54-73781

GLASS

3

20Y-54-38132

WEATHER STRIP

4

20Y-54-38142

SEAL

5

20Y-54-38152

SEAL

6

20T-54-75270

LATCH ASSEMBLY, L.H

7

20T-54-75280

LATCH ASSEMBLY, R.H

8

01435-30816

BOLT

9

20Y-54-14290

SROPPER

10

01580-11008

NUT

11

20Y-54-14590

HANDLE

12

01023-10616

SCREW

13

20Y-54-14310

STRIKER

14

20Y-54-14280

SCREW

15

20Y-54-37810

STPPER, L.H

16

01023-70416

SCREW

17

20Y-54-37820

STOPPER, R.H

18

01023-70416

SCREW

19

20Y-54-36834

BLOCK, L.H

20

20Y-54-36844

BLOCK, R.H

21

01252-50635

BOLT

22

01641-50608

WASHER

23

20Y-54-39152

ROLLER

24

205-54-63310

LOCK ASSEMBLY

25

01435-30820

BOLT

26

201-54-73180

BRACKET

27

01435-30820

BOLT

28

154-61-16570

WASHER

29

20Y-54-14721

LOCK

30

01435-30820

BOLT

|$32

20Y-54-36103

WINDOW ASSEMBLY, LOWER

31

20Y-54-36122

LATCH ASSEMBLY, L.H

32

20Y-54-36132

LATCH ASSEMBLY, R.H

33

20Y-54-36142

PLATE

34

20Y-54-36191

GROMMET

35

01225-70612

SCREW

36

20Y-54-36211

COVER

37

20Y-54-36113

GLASS

38

20Y-54-36171

SEAT

39

20Y-54-36230

SHIM, 2.0 MM

40

01370-00620

SCREW

41

20Y-54-36182

STOPPER

42

01435-30820

BOLT

43

20Y-979-2281

BRACKET

44

20Y-979-2290

SEAT

45

01435-30830

BOLT
