Запчасти Komatsu PC200SC-6 MULTI PATTERN КЛАПАН (WAY) (MULTI КЛАПАН)(№-) ГИДРАВЛИКА

|1

203-62-62501

VAVLE ASS'Y

1

203-62-59231

COVER

2

203-62-58911

LEVER

3

203-62-59260

PLATE

4

09822-00800

PLATE¤ OPERATING,SELECT VALVE

5

203-62-58950

BODY

6

236-10-12240

SPRING

7

203-62-58940

SHAFT

8

203-62-58980

COVER

9

01643-30623

WASHER

10

01010-80625

BOLT

11

01643-30823

WASHER

12

203-62-59270

WING BOLT

13

01640-20816

WASHER

14

04050-12015

PIN

15

07003-13642

GASKET

16

07000-13028

O-RING

|16

07000-03028

O-RING

17

01252-60616

BOLT

18

07043-00108

PLUG

19

04260-00793

BALL

20

07000-12060

O-RING

21

01010-81025

BOLT

22

01643-31032

WASHER

23

20Y-62-22271

ELBOW

24

201-60-11390

O-RING

25

20Y-62-19560

O-RING

26

07002-01423

O-RING

27

20Y-62-16630

NIPPLE

28

201-60-11390

O-RING

29

20Y-62-19560

O-RING

30

07002-01423

O-RING

31

20Y-62-25720

ELBOW

32

201-60-11390

O-RING

33

20Y-62-19560

O-RING

34

07002-01423

O-RING

35

07230-20210

UNION

36

07002-01423

O-RING

37

07236-10210

ELBOW

38

07002-01423

O-RING

39

07235-10210

ELBOW

40

07002-01423

O-RING

41

20Y-62-25631

BRACKET

42

20Y-62-25640

PLATE

43

01010-81230

BOLT

44

01643-31232

WASHER
