/ / / / / / ГИДР. БАК. (С ДАТЧИКОМ)(№-)
Запчасти Komatsu PC200SC-6 ГИДР. БАК. (С ДАТЧИКОМ)(№-) ГИДРАВЛИКА
1
2
2
3
4
5
6
7
8
9
10
10A
10A
11
11
11
12
13
14
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
44
45
45
46
47
|1
20Y-60-00070
HYDRAULIC TANK ASS'Y
|1
20Y-60-00063
HYDRAULIC TANK ASS'Y
1
TANK
|1
TANK
2
203-60-31100
ELBOW ASS'Y
|2
208-04-19130
ELBOW
3
203-60-31160
TUBE
4
07044-12412
PLUG
5
07002-02434
O-RING
6
07230-20628
UNION
7
07002-02434
O-RING
8
07236-10522
ELBOW
9
07002-02434
O-RING
10
07235-10315
ELBOW
10A
209-62-27580
TEE
|10A
07235-10315
ELBOW
11
07002-02034
O-RING
12
07236-10315
ELBOW
13
07002-02034
O-RING
14
07236-10210
ELBOW
15
07002-01423
O-RING
16
20Y-60-21510
ELEMENT
17
206-60-41221
STRAINER
18
12R-60-11300
VALVE ASS'Y
19
20Y-60-21240
SPRING
20
20Y-60-22530
COVER
21
07000-05180
O-RING
22
01010-81230
BOLT
23
01643-31232
WASHER
24
7861-92-4210
SENSOR
25
01252-40612
BOLT
26
01641-20608
WASHER
|27
20Y-60-22550
STRAINER ASS'Y
27
20Y-60-21311
STRAINER
28
207-60-61150
ROD ASS'Y
29
20Y-60-21320
HOLDER
30
12R-60-11230
SPRING
31
203-60-61140
COVER
32
07000-05180
O-RING
33
01010-81225
BOLT
34
01643-31232
WASHER
35
17A-60-11310
CAP ASS'Y
36
20Y-60-21470
ELEMENT
37
20Y-60-21460
NECK
38
20Y-60-21340
GASKET
|38
205-60-66211
GASKET
39
01252-70516
BOLT
|39
01220-40516
SCREW
40
01601-20513
WASHER
41
07285-00155
CLIP
42
20Y-60-21190
TUBE
|42
07270-61512
TUBE
43
20Y-60-22561
COVER
44
01220-40412
SCREW
45
20Y-60-22540
PLATE
46
01010-81635
BOLT
47
01643-31645
WASHER
