Запчасти Komatsu PC200SC-6 TELESCO РУКОЯТЬ SLIDE ЦИЛИНДР(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

20Y-957-5111

CYLINDER,(SEE FIG. Y1957-21A0)

2

01010-81675

BOLT

3

01643-31645

WASHER

4

01580-11613

NUT

5

20Y-957-5251

BRACKET

6

20Y-957-5260

PAD

7

01220-40812

SCREW

8

01010-81230

BOLT

9

01643-31232

WASHER

10

20Y-957-5291

TUBE,L.H

11

20Y-957-5311

TUBE,R.H

12

07372-21045

BOLT

13

07372-21060

BOLT

14

07372-21035

BOLT

15

01643-51032

WASHER

16

07000-13030

O-RING

17

20Y-957-6140

TUBE

18

20Y-957-5271

BAND

19

20Y-957-5281

BRACKET

20

01010-81035

BOLT

21

01643-51032

WASHER

22

07283-22738

CLIP

23

01599-01011

NUT

24

01643-31032

WASHER

25

20Y-957-5350

BLOCK

26

07372-21035

BOLT

27

01643-51032

WASHER

28

07000-13030

O-RING

29

201-62-71820

JOINT

30

21K-62-34310

FLANGE

31

07230-20628

UNION

32

07002-12434

O-RING

33

07121-00605

HOSE

34

20Y-957-6910

TUBE,R.H

35

20Y-957-6841

TUBE,L.H

36

20Y-957-6850

TUBE,L.H.

37

07000-13030

O-RING

38

07372-21035

BOLT

39

01643-51032

WASHER

40

20Y-957-5713

VALVE

40A

07000-13035

O-RING

41

01253-71425

BOLT

42

20Y-957-5240

PIN

43

04065-06020

RING

44

20Y-957-5230

PIN

45

20Y-957-2280

PLATE

46

01010-81225

BOLT

47

01643-31232

WASHER

48

20Y-957-6890

BRACKET

49

07283-32738

CLIP

50

01597-01009

NUT

51

01643-31032

WASHER

52

20Y-957-5210

BRACKET

53

20Y-957-5220

CAM FOLLOWER

54

01582-11210

NUT

55

01010-81230

BOLT

56

01643-31232

WASHER
