Запчасти Komatsu PC200SC-6 ОСНОВН. КОНСТРУКЦИЯ (РАБОЧАЯ ЛИНИЯ PPC) (ПАТРУБКИ ПРАВОЙ СТОЙКИ)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

20Y-62-27152

HOSE ASS'Y,R.H.

|1

20Y-62-27151

HOSE ASS'Y,R.H.

1

08034-00536

BAND

2

20Y-62-23311

HOSE¤ 1520MM

3

20Y-62-22790

BAND¤ RED

4

20Y-62-23321

HOSE¤ 1000MM

5

20Y-62-22820

BAND¤ BLUE

6

20Y-62-23342

HOSE¤ 2920MM

7

20Y-62-22830

BAND¤ WHITE

8

20Y-62-22850

BAND¤ GREEN

9

20Y-62-23351

HOSE¤ 2970MM

10

20Y-62-22840

BAND¤ BLACK

11

20Y-62-23361

HOSE¤ 3000MM

12

20Y-62-22860

BAND¤ BROWN

13

20Y-62-22170

CLAMP

|14

20Y-62-27230

HOSE ASS'Y

14

20Y-62-22890

HOSE¤ 2950MM

15

20Y-62-22790

BAND¤ RED

16

20Y-62-22910

HOSE¤ 1050MM

17

203-62-63220

HOSE¤ 3400MM

18

20Y-62-22820

BAND¤ BLUE

19

20Y-62-22190

CLAMP

20

20Y-62-22151

BLOCK

21

01010-81050

BOLT

22

01643-31032

WASHER

23

07235-10315

ELBOW

24

07002-02034

O-RING

25

07235-10210

ELBOW

26

07002-01423

O-RING

27

07230-20210

UNION

28

07002-01423

O-RING

29

208-62-17550

TEE

30

07002-01423

O-RING
