Запчасти Komatsu PC200LL-8 M8-7C КАБИНА НАКЛОН. НАСОС ЧАСТИ КОРПУСА

|$0

207-06-A1412

PUMP, CAB TILT

1

207-06-A2010

BASE ASSEMBLY

2

207-06-A2020

P ASSEMBLY

3

207-06-A2030

PIN, DOWEL

4

207-06-A2040

TUBE, SECTION

5

207-06-A2050

FILTER, SCREEN

6

207-06-A2060

TUBE, RETURN, 1/8

7

207-06-A2070

TUBE, RETURN, 90 DEG

8

207-06-A2080

CARTRIDGE

9

207-06-A2090

VALVE, CONTROL

10

207-06-A2110

SHAFT, INTERMEDIATE

11

207-06-A2120

SCREW

12

207-06-A2130

RESV, PLASTIC

13

207-06-A2140

CLAMP, HOSE, WORM GEAR

14

207-06-A2150

PLUG, RESEV, BREATHER-FILLER

15

207-06-A2160

BRACKET, PUMP

16

207-06-A2170

SCREW, 5/16-18X5/8

17

207-06-A2180

WASHER

18

207-06-A2190

SWITCH, 24 V DC

19

207-06-A2210

CABLE, INSULATED

20

207-06-A2220

WIRE ASSEMBLY

21

207-06-A2230

CORD ASSEMBLY

22

207-06-A1432

CONTROL STATION

23

207-06-A2250

BOOT, TERMINAL, #4 CABLE

24

207-06-A2260

BOOT, TERMINAL, 16 GA WIRE

25

207-06-A2270

MOTOR, DC

26

207-06-A2280

SCREW

27

207-06-A2290

CARTRIDGE

28

207-06-A2310

POPPET ASSEMBLY
